Drying Capacity
• 1000 sq. ft. of total drying tray area
• Includes 312 heavy-duty stainless steel wire trays (18″ × 26″, 3.25 sq. ft. each)
• 3 roll-in, extra heavy-duty removable aluminum racks for easy loading and unloading
Construction & Dimensions
• Approx. Size: 161″ L × 76″ W × 85″ H
• Approx. Weight: 3,800 lbs
• Exterior: .060 heavy-duty aluminum
• Interior: .040 thick aluminum
• Floor: .1875 thick aluminum
• Three heavy-duty insulated doors for secure access
• Heavy-duty stainless steel hinges and latches
Insulation
• Floor, walls, and ceiling: 2.125″ polyisocyanurate foam insulation
Heating & Airflow
• Heat Source: Electric – 480 Volt, 3 Phase
• Circulation Fans: 2 heavy-duty circulation fans (12,000 CFM), motors mounted on exterior to prevent contamination
• Ventilation: 1 variable speed exhaust fan to vent moist air outside
• Air Filter: 2 – 16″ × 20″ inlet air filters
Temperature Control
• Programmable electronic controller to manage temperature and heating elements
• Temperature cycling conserves energy once the desired drying temp is reached
Racking System
• 300 stainless steel trays roll in and out for efficient tray handling and cleaning
Electrical & Energy Efficiency
• 2-speed fan control to reduce energy use during final drying stages
• Heating elements cycle on/off automatically once set temp is achieved
Shipping & Manufacturing
• Made and designed in the USA
• Shipping costs to be determined upon readiness
